Model / model x10
Product name / type 10 inch full frequency speaker
Frequency response / fre.response 50Hz-20KHz ± 3dB
Unit / drivers 10 "bass unit / 34 core treble driver
Withstand power / power 250W continuous, 1000W peak
Sensitivity 93dB ± 3dB
Maximum sound pressure / max.spl 123dB continuous, 129dB peak
Impedance / impedance 8 ohms
Diffusion angle / 90 ° horizontal, 60 ° vertical (- 6dB)
Size (mm) (d) 195 x (H) 527x (W) 350
Model / model x602
Product name / type double 6-inch full frequency speaker
Frequency response / fre.response 50Hz-20KHz ± 3dB
Unit / drivers 6 "bass unit / 34 core treble driver
Withstand power / power 150W continuous, 600W peak
Sensitivity 93dB ± 3dB
Maximum sound pressure / max.spl 123dB continuous, 129dB peak
Impedance / impedance 8 ohms
Diffusion angle / 90 ° horizontal, 60 ° vertical (- 6dB)
Size (mm) (d) 170 x (H) 270x (W) 530
Model / model x8
Product name / type 8-inch full frequency speaker
Frequency response / fre.response 50Hz-20KHz ± 3dB
Unit / drivers 8 "bass unit / 34 core treble driver
Withstand power / power 180W continuous, 720W peak
Sensitivity 93dB ± 3dB
Maximum sound pressure / max.spl 123dB continuous, 129dB peak
Impedance / impedance 8 ohms
Diffusion angle / 90 ° horizontal, 60 ° vertical (- 6dB)
Size (mm) (d) 275 x (H) 435x (W) 300
Model / model x115
Product name / type 15 inch subwoofer
Frequency response / fre.response 35hz-300hz ± 3dB
Unit / drivers 15 "bass unit
Withstand power / power 500W continuous, 2000W peak
Sensitivity 101dB
Maximum sound pressure / max.spl 130dB continuous, 136dB peak
Impedance / impedance 8 ohms
